Detailed Characteristics
Power Supply
Power supply AC Input voltage, Volt(1-1)
100~120V/200~240V
Power supply AC Input Frequency Range, Hz
47~63
Power supply AC Input current, Amp(1-2)
20(1-3)
Hardware Configuration
Networking connection mode
RJ45 Ethernet 10/100M
Miner Size (Length*Width*Height, w/o package), mm(2-1)
400*195*290
Miner Size (Length*Width*Height, with package),mm
570*316*430
Gross weight, kg(2-2)
14.5
Environment Requirements
Operation temperature, °C
0~45
Storage temperature, °C
-40~85
Operation humidity(non-condensing), RH
10~90%
Operation altitude, m(3-1)
≤2000
NOTE:
(1-1) Caution: Wrong input voltage may probably cause miner damaged
(1-2) Max condition: temperature 40°C, altitude 0m
(1-3) Two AC input wires, 10A per wire
(2-1) Including PSU size
(2-2) Including PSU weight
(3-1) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m
Please click here to refer to the all certificates of the products.
